In part 2 of the series
, I delivered a brief primer on the service architecture in Microsoft Dynamics GP 2015 and how you are able to consume services natively created with Dexterity. There are two types of services that can be created: services that wrap existing windows and forms functionality, i.e., creating a customer; and services that can wrap around existing sanScript procedures, i.e, retrieving customer information. The truth is, none of that stuff would be possible without the ability to interoperate with the Microsoft .NET Framework.
Today, I'm going to show you some of the .NET interop capabilities built into Dexterity 14.0 and how these can enhance the user experience and your application integration capabilities. The example used in this post is based on my previous article, Building a COM Interop Assembly to use with Microsoft Dexterity
, which showed how we had to leverage .NET's ability to expose an assembly via COM interfaces, so we could reference its methods using Dexterity. In that particular example, I built some standard methods to expose the sine, cosine, and tangent trigonometric functions to a Dexterity application. This time around, I will show how to build the same functionality taking full advantage of Dexterity's new .NET interop capabilities.
The user experience will be slightly different this time. In addition to a window that will allow you to calculate any of the trigonometric functions on a specific angle (entered in degrees), we will display a .NET form showing a visual representation of that angle. The .NET form will be dynamically built and displayed from Dexterity using the methods and properties provided by the Form class (System.Windows.Forms)
and the visual drawings will be delivered using the classes exposed in the System.Drawing namespace
1. The first things we must do is incorporate references to the corresponding assemblies for the Forms class and Drawing namespaces. As developer, the first thing you will notice is the enhancements to Dexterity's Library Definition
window, which now allows for the selection of a .NET Assembly library type.
Once the type has been selected, you can browse out to the different .NET assemblies loaded on your operating system.
In particular, what I like is the ability to select the .NET Framework assembly that I want to work with directly, as opposed to having to compile my application for a specific Framework version as you normally would do with Visual Studio.
Resource Explorer will now…
